Simple Distillation Unit

Simple Distillation Unit
Simple Distillation Unit
Product Code : real01
Product Description

Our company is looked upon as the topmost manufacturer and exporter of Simple Distillation Unit. Operates at atmospheric pressure, this unit is available with different volumes of vessels in order to meet diverse requirements of clients. This Simple Distillation Unit is stringently tested on various quality parameters before the final delivery in market.


  • Can resist high heat
  • Sturdy design
  • Low maintenance

This is a general-purpose batch distillation unit to be operated at .

Heating bath heats and evaporates the contents of the vessel. The vapours are then condensed in the condenser, and are collected in a container or a receiver.

The unit is complete with a spherical vessel, drain valve, heating bath, thermometer pocket, liquid inlet, vapour pipeline and a coil condenser.

A receiver with drain valve can be added optionally. Refer Selection chart for different options available for heating bath, vessel and receiver.

The unit is available in vessel size of 20, 50, 100 and 200 Litre

Unit Cat.Ref.     Reactor capacity     Bath KW     Vapour Line     Condenser HTA M²
SDU20                    20L                            4.5                    80DN           0.35
SDU50                    50L                              6                     100DN         0.5
SDU100                 100L                            9                      150DN        1.5
SDU200                 200L                          12                      150DN        1.5
